Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | 8910-PS-DC |
| Manufacturer | MTL Instruments / Eaton |
| Product Series | MTL 8000 Series / IS Module |
| Product Type | DC System Power Supply |
| Input Voltage | 18.5–36 VDC |
| Nominal Input | 24 VDC |
| Output Voltage | 12 VDC ±5% |
| Output Current | 4.9 A |
| Output Power | Approx. 58.8 W |
| Input-Output Isolation | 50 VAC rms / 720 VDC |
| Redundancy | Supports connection of a second power supply for redundancy |
| Mounting | 8711-CA-NS / 8712-CA-NS node service carrier or 8717-CA-PS power supply carrier |
| Hazardous Area Approval | Class I, Div. 2, Groups A, B, C, D, T4 / Zone 2, IIC, T4 |
| EMC Compliance | EN 50081-2 / EN 50082-2 |
| Electrical Safety | EN 61010-1 |
| Operating Temperature | -40°C to +70°C at 60% load |
| Full-Load Temperature | -40°C to +55°C in optimum orientation |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% RH, non-condensing |
| Product Weight | Approx. 0.775 kg |
| Shipping Weight | Approx. 2 kg |
| Dimensions | Approx. 62 × 75 mm |
FAQ
FAQ
Q1: What is the 8910-PS-DC used for?
A: It is a DC system power supply used to provide regulated power to MTL 8000 Series nodes and associated industrial control equipment.
Q2: What is the input voltage of the 8910-PS-DC?
A: It accepts 18.5–36 VDC, making it suitable for nominal 24 VDC plant power systems.
Q3: What is the output voltage and current?
A: It provides 12 VDC ±5% with a maximum output capacity of 4.9 A.
Q4: Can two 8910-PS-DC units be used for redundancy?
A: Yes. The 8910-PS-DC supports a second power supply for redundant operation, improving system availability.
Q5: Can the 8910-PS-DC be used in hazardous areas?
A: Yes. The specification lists approval for Class I, Division 2, Groups A–D, T4 and Zone 2, IIC, T4 hazardous locations.
Q6: What is the operating temperature range?
A: It can operate from -40°C to +70°C at 60% load. At full load in the optimum mounting orientation, the specified range is -40°C to +55°C.
Q7: What is the weight of the 8910-PS-DC?
A: The product weighs approximately 0.775 kg, with a listed shipping weight of approximately 2 kg.
Q8: Is 8910-PS-DC a GE product?
A: No. Despite some aftermarket listings labeling it “GE 8910-PS-DC,” the reliable manufacturer documentation identifies 8910-PS-DC as an MTL Instruments product, now within the Eaton portfolio.
