Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | DS200DTBDG1ABB |
| Product Type | Contact Output Expansion / Terminal Board |
| Series | Speedtronic Mark V (DS200 Series) |
| Functional Description | Terminal board providing contact output expansion and signal termination for turbine control systems |
| Terminal Blocks | 2 blocks with ~107 terminals each for signal wires |
| Connectors | 3 × 34‑pin, 3 × 40‑pin connectors; jumpers and test points |
| PCB Coating | Normal protective coating |
| Mounting | Rack‑mount printed circuit board in control cabinet |
| Operating Temperature | Approx. –20 °C to +70 °C (industrial range) |
| Storage Temperature | Standard PCB storage range |
| Relative Humidity | 5 %–95 % non‑condensing |
| Power Supply | Internal backplane power (typical Mark V system) |
| Code / Standards | GE Mark V system compatibility |
| Dimensions (approx.) | ~285 mm × 76 mm × 76 mm (board footprint ~11.25″ × ~3″ × ~3″) |
| Weight | ~0.8 kg (~1.76 lbs) |
| Status | Legacy / surplus industrial board |
FAQ
FAQ
Q1. What is the DS200DTBDG1ABB board used for?
It is a contact output expansion terminal board that provides additional terminal connections and contact signal routing inside GE Speedtronic Mark V turbine control systems.
Q2. Which GE control system series does this part belong to?
It is part of the GE Speedtronic Mark V DS200 series of control modules.
Q3. What is the primary function of this board?
Its main role is to terminate control signals and expand contact outputs for relay and field connections within the control rack.
Q4. How many terminals does the board support?
It includes two terminal blocks, each housing approximately 107 signal terminals.
Q5. What types of connectors are on the DS200DTBDG1ABB?
It features multiple connectors, including three 34‑pin and three 40‑pin connectors, along with jumpers and test points for configuration.
Q6. What are the approximate physical dimensions of this board?
The board’s approximate overall size is around 285 mm × 76 mm × 76 mm.
Q7. How much does the DS200DTBDG1ABB weigh?
It weighs about 0.8 kg (approximately 1.76 lbs).
Q8. Can this board still be purchased new?
This is a legacy Mark V Speedtronic component; new production has ceased, but it is often available as surplus or rebuilt stock.
