Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | DS200TCEAG1BNE |
| Product Type | Emergency Overspeed Board |
| Series | Speedtronic Mark V (DS200/Mark V series) |
| Function | Monitors turbine overspeed and flame detection conditions and generates emergency trip/shutdown commands to protect gas and steam turbines; interfaces with other trip logic boards via bayonet connectors. |
| Typical Use | Critical safety and turbine shutdown logic in industrial turbine control systems; overriding speed protection. |
| Processor / Firmware | On‑board microprocessor with programmable PROM modules. |
| Connectors | Pair of bayonet connectors for system integration. |
| Jumpers / Protection | ~30 jumpers for configuration; 3 on‑board circuit protection fuses. |
| Mounting | Rack‑mount printed circuit board inside GE Mark V turbine control cabinet. |
| Operating Temperature | Typical industrial turbine range (exact manufacturer range not publicly specified). |
| Humidity | Industrial non‑condensing environment (standard range). |
| Dimensions (approx.) | ~160 mm × 160 mm × 120 mm |
| Weight | ~1.0 kg (2.2 lbs shipping weight estimate based on similar Mark V emergency boards). |
| Status | Legacy turbine control safety board; new production has ended, but units are commonly available as surplus or refurbished. |
FAQ
FAQ
Q1. What is the DS200TCEAG1BNE?
It is an emergency overspeed protection board in GE’s Speedtronic Mark V turbine control system that detects overspeed and flame trip conditions to initiate a protective shutdown.
Q2. Which control system family uses this board?
It is used in GE Speedtronic Mark V (DS200 series) gas and steam turbine control platforms.
Q3. What does “overspeed protection” mean?
Overspeed protection monitors turbine speed and triggers a safe shutdown if the turbine exceeds its maximum safe speed to prevent mechanical damage.
Q4. How does the DS200TCEAG1BNE connect to the system?
This board connects via bayonet connectors and integrates with other Mark V modules for trip logic and control.
Q5. Does this board include configuration features?
Yes — it has hardware jumpers (~30) for board location and functional configuration as defined by Mark V system schematics.
Q6. Are there diagnostic protections on this board?
Yes — the board includes onboard fuses for circuit protection and leverages internal logic for safety condition monitoring.
Q7. What are its approximate size and weight?
The approximate board size is around 160 mm × 160 mm × 120 mm and it weighs about 1.0 kg, typical of GE Mark V protection boards.
Q8. Is DS200TCEAG1BNE still manufactured by GE?
No — it is a legacy Mark V emergency overspeed component; new production is discontinued and units are generally found as surplus or refurbished stock.
