Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | DS200TCQAG1BGD |
| Product Type | RST Analog I/O Board |
| Series | Speedtronic Mark V (DS200) |
| Function | Analog input/output conditioning and signal processing for turbine control — routes and scales analog signals between terminal boards and Mark V backplane logic. |
| Application | Gas and steam turbine automation and process control I/O interfacing. |
| Connectors | Typically 20-pin connector interfaces for ribbon wiring (JKX, JKZ, JKY) to external wiring harnesses. |
| Signal Types | General analog signals supporting scaling and routing — exact compatible sensor types depend on system design. |
| Status Indicators | Board may include diagnostic LEDs (varies by production batch). |
| Mounting | Rack-mount printed circuit board inside Mark V control cabinet. |
| Operating Temperature | Typical industrial control range (not officially published). |
| Humidity | Industrial non-condensing environment tolerance. |
| Dimensions (approx.) | ~160 mm × ~160 mm × ~120 mm (standard Mark V analog board form factor). |
| Weight | ~0.8 kg (~1.76 lbs) (estimate based on similar Mark V analog I/O boards). |
| Status | Legacy industrial turbine control analog I/O board — often available as surplus or refurbished stock. |
FAQ
FAQ
Q1. What is DS200TCQAG1BGD used for?
It’s an RST analog I/O board designed for GE Speedtronic Mark V turbine control systems, handling analog input/output conditioning between terminal boards and the system backplane.
Q2. Which control system family includes this board?
This board belongs to the General Electric Speedtronic Mark V DS200 series.
Q3. What type of signals does it process?
It processes generic analog signals coming from terminal boards for conditioning and routing to control logic — specific compatible signal types depend on the control configuration.
Q4. How is it mounted?
The board mounts inside a Mark V control rack as a printed circuit board interfacing with the system backplane.
Q5. Does DS200TCQAG1BGD include diagnostic indicators?
Some board variants may include LEDs for power or basic status indication, though specifics vary by batch and revision.
Q6. What are its approximate physical dimensions?
The board’s approximate dimensions are about 160 mm × 160 mm × 120 mm.
Q7. How much does this board weigh?
It weighs around 0.8 kg (~1.76 lbs), typical of Mark V analog I/O boards.
Q8. Is DS200TCQAG1BGD still manufactured?
No — it is a legacy Speedtronic Mark V module and is generally available through surplus or refurbished inventories rather than new production.
