Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | GE DS200TCTGG1AEE |
| Type | Relay Board |
| Function | Relay output interface for control and protection circuits in GE Mark V systems |
| Compatible Systems | GE Mark V Control System |
| Input Voltage | 24 VDC control logic |
| Output Type | Electromechanical relays |
| Number of Relays | Up to 12 output relays |
| Contact Ratings | Suitable for industrial control loads |
| Contact Configuration | Form C (SPDT) per relay |
| Isolation | Control-to-contact electrical isolation |
| Protection Features | Flyback suppression and transient protection |
| Communication Interface | Mark V backplane connection |
| Switching Time | Millisecond-level response |
| Operating Temperature Range | -20°C to 70°C |
| Storage Temperature Range | -40°C to 85°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Mounting | Panel or rack mount |
| Dimensions (HxWxD) | 210 x 150 x 35 mm |
| Weight | 0.8 kg |
FAQ
FAQ
Q1: What is the primary function of the GE DS200TCTGG1AEE board?
A1: It provides relay outputs for driving external devices such as contactors, alarms, and interlocks from the Mark V controller.
Q2: What type of relays are used on this board?
A2: The board uses industrial-grade electromechanical relays suitable for control and protection circuits.
Q3: How many outputs are available on this relay board?
A3: The board supports up to 12 independent relay outputs.
Q4: Are the relay contacts isolated from the control circuitry?
A4: Yes, electrical isolation is provided between the Mark V logic circuits and the relay contacts.
Q5: Can this board be used for safety-related functions?
A5: It is commonly used in protection and interlock circuits, but overall safety integrity depends on system-level design.
Q6: How is the board powered?
A6: The board receives power through the Mark V backplane from the 24 VDC system supply.
Q7: Does the board include protection for inductive loads?
A7: Yes, flyback diodes and transient suppression circuits are included to protect against switching surges.
Q8: Is any configuration required at the board level?
A8: No local configuration is needed; all control logic is managed by the Mark V controller.
