Technical Specifications
| Parameter | Specification |
|---|---|
| Model | GE DS200VPBLG1ADD |
| Product Type | Mark V VME Backplane Board |
| System Compatibility | GE Mark V Speedtronic Control System |
| Primary Function | Provides VMEbus interconnect, signal routing, and power paths |
| Supported Modules | VME-based Mark V control and interface cards |
| Bus Architecture | VME64-compatible |
| Signal Routing | High-integrity backplane traces with controlled impedance |
| Power Distribution | Integrated bus bars and regulated supply pathways |
| Connector Type | Multi-slot VME connectors |
| Mounting Method | Chassis-mounted inside Mark V VME rack |
| Dimensions | 250 × 185 × 25 mm |
| Weight | 0.8 kg |
FAQ
FAQ
Q1: What is the main function of the DS200VPBLG1ADD VME Backplane Board?
A1: It provides the essential communication, power distribution, and interconnection pathways for VME-based cards within the Mark V control system.
Q2: How does this backplane support module communication?
A2: It uses VMEbus architecture to route data, control, and interrupt signals between all installed modules.
Q3: Can this backplane board be used with non-GE VME modules?
A3: It is designed specifically for Mark V system modules, and using third-party boards is not recommended due to signal integrity and compatibility requirements.
Q4: What happens if a slot or bus line on the backplane becomes damaged?
A4: The affected module may lose communication, experience intermittent faults, or fail to initialize properly, requiring board replacement.
Q5: Does the DS200VPBLG1ADD provide any form of electrical protection?
A5: Yes, it incorporates controlled grounding, power bus management, and routing practices that help mitigate electrical noise and cross-talk.
Q6: How can system faults related to the backplane be diagnosed?
A6: Faults often appear as communication errors, module dropout, or diagnostic codes, which can be traced through module LEDs and system fault logs.
Q7: Are there firmware or software elements associated with this board?
A7: No, the backplane is purely hardware-based and contains no programmable components.
Q8: What precautions should be taken during installation?
A8: Ensure proper chassis grounding, avoid bending connectors, use ESD protection, and verify alignment of all VME modules before securing them.
