Technical Specifications
| Item | Specification |
|---|---|
| Model | DS215TCQAG1BZZ01A / DS200TCQAG1BEC |
| Type | Analog Input/Output Board |
| Supported Signal Types | Voltage, 4–20 mA current, Thermocouple, LVDT/LVDR, Servo valve output |
| Analog Input Range | ±10 V, ±5 V, ±2 V, ±1 V, 0–5 V, 0–10 V |
| Resolution / Accuracy | 16-bit, ±0.1% full scale |
| Conversion Time | Approx. 2 µs |
| Signal Conditioning | Signal scaling, thermocouple compensation, analog I/O adjustment |
| Interface | Multiple 34‑pin and 40‑pin connectors, with jumpers and LED status indicators |
| Installation Environment | Industrial control cabinets, turbine control systems, power plants |
| Operating Temperature | –40 °C … +70 °C |
| Protection Rating | IP20 |
| Dimensions | 262 × 185 × 39 mm |
| Weight | 0.8 kg |
FAQ
FAQ
Q1: What analog signals does this board support?
A1: Voltage, current, thermocouple, LVDT/LVDR, servo valve outputs, and other analog signals.
Q2: What is the resolution and accuracy of analog I/O?
A2: 16-bit resolution, ±0.1% full scale accuracy.
Q3: How fast is the signal conversion?
A3: Conversion time for analog I/O is approximately 2 microseconds.
Q4: How does the board connect to terminal boards?
A4: Via 34‑pin or 40‑pin connectors and jumpers for signal acquisition and output.
Q5: Does it support 4–20 mA outputs?
A5: Yes, it supports 4–20 mA outputs for controlling devices or sensors.
Q6: What is the operating temperature range?
A6: –40 °C to +70 °C, suitable for industrial environments.
Q7: How does the board indicate status or faults?
A7: LED indicators display power, processing activity, and error states.
Q8: What are the typical applications?
A8: Power plants, turbine control systems, petrochemical, water treatment, and other industrial automation and process control systems.
