Technical Specifications
| Item | Specification |
|---|---|
| Model | IC660EBA024 |
| Product Type | I/O Block Electronics Module |
| Block Type | Universal (Configurable as Input or Output) |
| Power Supply | 24/48 VDC with redundant input capability |
| Number of Channels | 16 (configurable as input or output) |
| Input Voltage Range | 0–60 VDC |
| Output Voltage Range | 0–60 VDC |
| Max Output Current | Up to 2 A per point |
| Diagnostics | Short circuit, open circuit, overcurrent checks |
| LED Indicators | Power, input/output status per channel |
| Communication | Genius Bus Network Interface |
| Mounting Method | Installed in IC660 terminal block housing |
| System Compatibility | GE Fanuc Genius Series |
| Dimensions | 224.4 x 88.9 x 100 mm |
| Weight | 1.8 kg |
FAQ
FAQ
Q1: How many channels does the IC660EBA024 support?
It supports up to 16 configurable channels for input or output.
Q2: What power supply does it require?
It operates on 24 or 48 VDC and supports redundant inputs.
Q3: Does it include diagnostic features?
Yes, it supports diagnostics for short circuit, open circuit, and overcurrent.
Q4: What systems is it compatible with?
It is compatible with GE Fanuc Genius Bus communication systems.
Q5: Is hot-swapping supported?
No, it must be installed or removed with power off.
Q6: What is the max output per channel?
Each output channel can deliver up to 2 amps.
Q7: How can I view the module’s status?
It includes LED indicators for each channel and power status.
Q8: Does it have a communication interface?
Yes, it connects via Genius Bus for system communication.
