Technical Specifications
| Item | Specification |
|---|---|
| Model | IC660EBA026 |
| Product Type | I/O Block Electronics Module |
| Block Type | Universal (Configurable as Input or Output) |
| Power Supply | 24/48 VDC with redundant input support |
| Number of Channels | 16 (individually configurable) |
| Input Voltage Range | 0–60 VDC |
| Output Voltage Range | 0–60 VDC |
| Max Output Current | Up to 2 A per point |
| Output Type | Transistor (Sourcing output) |
| Diagnostics | Overcurrent, short circuit, open circuit detection |
| LED Indicators | Per-channel status and power status |
| Communication | Genius Bus network interface |
| Mounting Method | Installed in IC660 terminal block housing |
| System Compatibility | GE Fanuc Genius I/O series |
| Dimensions | 224.4 x 88.9 x 100 mm |
| Weight | 0.898 kg |
FAQ
FAQ
Q1: Are the channels on the IC660EBA026 individually configurable?
Yes, all 16 channels can be configured as either input or output.
Q2: What input voltage does the module support?
It supports 24 or 48 VDC power input with redundancy capability.
Q3: Does the module have built-in diagnostics?
Yes, it includes detection for overcurrent, short circuit, and open circuit.
Q4: What communication protocol does it use?
It uses the Genius Bus communication network.
Q5: Can the outputs drive loads directly?
Yes, each output can supply up to 2 amps.
Q6: Is hot-swapping supported for this module?
No, power must be removed before installation or replacement.
Q7: Are there LED indicators?
Yes, each channel has an LED indicator, along with a power status LED.
Q8: What are the typical industrial applications?
The module is used for discrete signal control in industrial automation systems.
