Technical Specifications
| Item | Specification |
|---|---|
| Model Number | IC660TSD021 |
| Brand | GE Fanuc |
| Product Type | Terminal Assembly |
| Number of Terminals | 40 |
| Terminal Type | Spring clamp |
| Wire Size Range | 14–22 AWG (1.5–0.34 mm²) |
| Voltage Rating | 300 V AC/DC |
| Current Rating | 10 A per terminal |
| Mounting Method | DIN rail or panel mount |
| Operating Temp | -20°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Dimensions | 110 x 150 x 50 mm |
| Weight | 0.5 kg |
FAQ
FAQ
Q1: What is the main function of the IC660TSD021 Terminal Assembly?
It provides organized wire termination for GE Fanuc PLC systems with 40 spring clamp terminals.
Q2: How many terminals does this assembly have?
It includes 40 spring clamp terminals.
Q3: What wire sizes are supported?
Compatible with 14 AWG to 22 AWG wires (1.5 to 0.34 mm²).
Q4: What is the current rating per terminal?
Each terminal supports up to 10 A.
Q5: How can this terminal assembly be mounted?
Mountable on DIN rails or panels.
Q6: What terminal type is used in this assembly?
Uses spring clamp terminals for secure, tool-free wiring.
Q7: Is the assembly suitable for industrial environments?
Yes, it operates between -20°C and +60°C, suitable for industrial use.
Q8: What are the physical dimensions and weight?
Dimensions: 110 x 150 x 50 mm; Weight: 0.5 kg.
