Technical Specifications
| Item | Specification |
|---|---|
| Module Model | GE Fanuc IC693MDL733 |
| Input Type | Positive/Negative Logic Input |
| Number of Input Points | 32 points |
| Input Voltage Range | 0–30 VDC |
| Logic “1” Level | 15–30 VDC |
| Logic “0” Level | 0–5 VDC |
| Typical Input Current | Approx. 7 mA |
| Isolation | Group-isolated inputs |
| Response Time | 1 ms (typical) |
| Connection Method | Terminal block |
| Operating Temperature | 0°C to 60°C |
| Dimensions | 150 × 100 × 70 mm |
| Weight | 0.4 kg |
FAQ
FAQ
Q1: What type of input module is the IC693MDL733?
A1: It is a DC input module that supports both positive and negative logic.
Q2: How many input points does the module provide?
A2: It provides 32 independent input points.
Q3: Does the module require an external power supply?
A3: Yes, external DC field power is required for input devices.
Q4: What is the typical input current of the module?
A4: Approximately 7 mA.
Q5: What types of devices can be connected to the module?
A5: Standard DC discrete devices such as proximity switches and push buttons.
Q6: Does the module provide input isolation?
A6: Yes, it features group-isolated inputs for improved noise immunity.
Q7: Which PLC series is this module compatible with?
A7: It is compatible with the GE Fanuc Series 90-30 PLC family.
Q8: Is special maintenance required?
A8: No special maintenance is required beyond routine terminal and wiring checks.
