Technical Specifications
| Item | Specification |
|---|---|
| Model | GE Fanuc IC695ALG112 |
| Product Type | RX3i Analog Input Module |
| Series | IC695 / RX3i I/O Modules |
| Function | Accepts analog signals from field devices and converts them to digital data for RX3i PLC processing |
| Input Channels | 8 differential or 16 single-ended channels |
| Input Range | ±10 V, 0–10 V, 0–20 mA, 4–20 mA (configurable per channel) |
| Resolution | 16-bit ADC |
| Accuracy | ±0.1% of full scale |
| Isolation | Channel-to-channel and channel-to-backplane isolation |
| Update Rate | 5 ms per channel (typical) |
| Power Consumption | 2 W typical |
| Mounting Type | Plug-in module for RX3i I/O backplane |
| LED Indicators | Status and error LEDs for each channel |
| Dimensions | 34 x 140 x 145 mm |
| Weight | 0.45 kg |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Application | Used in RX3i PLC systems to acquire analog signals from sensors like temperature, pressure, and flow transmitters |
| Certifications | UL, CE |
FAQ
FAQ
Q1: What is the main function of the IC695ALG112 module?
A1: It receives analog signals from field devices and converts them to digital data for RX3i PLC processing.
Q2: How many input channels does it have?
A2: Supports 8 differential channels or 16 single-ended channels.
Q3: What types of input signals are supported?
A3: ±10 V, 0–10 V, 0–20 mA, 4–20 mA, configurable per channel.
Q4: What is the resolution and accuracy?
A4: 16-bit ADC with ±0.1% of full-scale accuracy.
Q5: Does it provide isolation protection?
A5: Yes, channel-to-channel and channel-to-backplane isolation.
Q6: What is the update rate?
A6: Approximately 5 ms per channel.
Q7: Can it be hot-swapped?
A7: It can be installed or removed within RX3i I/O systems, following PLC safety procedures.
Q8: What should be noted during installation?
A8: Align the module with the backplane slot, prevent static discharge, and check LED status to ensure proper installation.
