Technical Specifications
| Item | Specification |
|---|---|
| Model | IC695HSC308 |
| Series | PACSystems RX3i |
| Type | High-Speed Counter Module |
| Number of Channels | 8 |
| Maximum Count Frequency | 1 MHz |
| Input Signal Type | Single-ended or differential pulse input |
| Input Voltage Range | 5 ~ 24 V DC |
| Resolution | 32-bit counting |
| Input Isolation | Optical isolation between channels |
| Supported Modes | Counting, frequency measurement, encoder mode |
| Power Supply | 24 V DC |
| Power Consumption | 8 W |
| Operating Temperature | 0 ~ 60 ℃ |
| Storage Temperature | -40 ~ 85 ℃ |
| Dimensions | 132 x 50.8 x 70 mm |
| Weight | 0.336 kg |
FAQ
FAQ
Q1: How many input channels does this module have?
It has 8 high-speed input channels.
Q2: What is the maximum counting frequency?
The maximum counting frequency is 1 MHz.
Q3: What types of input signals are supported?
Supports single-ended and differential pulse inputs.
Q4: What is the input voltage range?
Input voltage range is 5 ~ 24 V DC.
Q5: What operation modes are supported?
Supports counting, frequency measurement, and encoder mode.
Q6: Does the module provide isolation protection?
Yes, it features optical isolation between channels for improved noise immunity.
Q7: What are the dimensions and weight?
Dimensions are 132 x 50.8 x 70 mm, weight approximately 0.336 kg.
Q8: What applications is this module suitable for?
Ideal for high-speed counting, motion control, speed detection, and industrial process monitoring.
