Technical Specifications
| Item | Specification |
|---|---|
| Model | GE Fanuc IC697BEM721 |
| Type | I/O Link Interface Module |
| Series | IC697 Series |
| Manufacturer | GE Fanuc |
| Function | Provides interface between PLC CPU and remote I/O devices |
| Supported I/O | Digital and analog I/O via I/O Link |
| Maximum Nodes | 32 nodes per link |
| Data Transfer Rate | 500 kHz typical |
| Isolation | Backplane isolated |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | –40°C to +85°C (–40°F to 185°F) |
| Power Requirements | 5 VDC ±5%, 200 mA typical |
| Dimensions | 201 × 40 × 153 mm |
| Weight | 0.26 kg |
FAQ
FAQ (English Version)
Q1: What is the primary purpose of this module?
It provides an interface between the PLC CPU and remote I/O devices, enabling data transfer and control.
Q2: How many I/O nodes can it support?
Up to 32 nodes can be connected to a single I/O Link.
Q3: What types of I/O does it support?
Supports both digital and analog I/O signals.
Q4: What is the data transfer rate?
Typical data transfer rate is 500 kHz.
Q5: Does the module provide isolation protection?
Yes, it provides backplane isolation for safe operation.
Q6: What is the operating temperature range?
Operating temperature is 0°C to 60°C (32°F to 140°F).
Q7: What are the module dimensions?
Dimensions are 201 × 40 × 153 mm, suitable for standard rack installation.
Q8: What is the power consumption?
Requires 5 VDC ±5%, typical current 200 mA.
