Technical Specifications
| Parameter | Details |
|---|---|
| Model | IS200EPSMG2RED |
| Module Type | Exciter Power Distribution / Power Supply Module |
| Application | GE EX2100 Excitation System (Redundant version – “RED”) |
| Input Voltage | 125 V DC from exciter supply bus |
| Output Voltages | +5 V DC, +15 V DC, +24 V DC regulated control voltages |
| Additional Outputs | +24 V DC auxiliary supply; isolated +70 V DC contact-wetting supply |
| Special Feature | Redundant-design module for dual-channel exciter systems |
| Functional Role | Distributes and regulates DC power to control processors and auxiliary protection devices |
| Supported Loads | Control processors, fan modules, crowbar assemblies, detection modules, terminal board circuits |
| Installation | Inserts into the EPBP backplane inside the exciter control cabinet |
| Dimensions | 285 × 205 × 45 mm |
| Weight | 1.1 kg |
FAQ
FAQ
Q1: What is the purpose of the IS200EPSMG2RED module?
A1: It serves as a redundant power distribution and regulation module for GE EX2100 exciter systems, supplying essential control voltages.
Q2: What is the difference between the G1A/G1B versions and the G2RED version?
A2: The G2RED version is designed for redundant exciter architectures, providing improved reliability and continuity.
Q3: What is the input power for this module?
A3: It operates on a 125 V DC supply from the exciter’s main DC bus.
Q4: What output voltages does it generate?
A4: It generates +5 V, +15 V, and +24 V DC for internal control circuits and auxiliary devices.
Q5: Which components depend on this module for power?
A5: Exciter control processors, fan units, crowbar and protection assemblies, and contact circuits on terminal boards.
Q6: Where is the module physically installed?
A6: It is seated in the EPBP backplane slot in the exciter control cabinet.
Q7: Does the module support hot-swap or live replacement?
A7: It does not support hot-swap; the exciter must be in a safe shutdown state before replacement.
Q8: How heavy is the IS200EPSMG2RED?
A8: The module weighs approximately 1.1 kg.
