Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation) |
| Product Model | IC200ALG430F |
| Product Type | Analog Mixed I/O Module |
| Series | VersaMax I/O |
| Function | Provides combined analog current input and analog current output capability in a single module |
| Input Channels | 4 analog current input channels |
| Output Channels | 2 analog current output channels |
| Input Signal Type | Differential current input |
| Output Signal Type | Single-ended current output |
| Input Range | 4–20 mA |
| Output Range | 4–20 mA |
| Resolution | 12-bit |
| Input Resolution | 4 µA = 8 counts |
| Output Resolution | 4 µA = 8 counts |
| Input Impedance | 200 Ω maximum |
| Output Load Resistance | 1250 Ω maximum |
| Input Accuracy | ±0.3% typical of full scale; ±0.5% maximum at 25°C |
| Output Accuracy | ±0.3% typical of full scale; ±0.5% maximum at 25°C |
| Input Update Rate | 0.4 ms |
| Output Update Rate | 0.3 ms |
| Input Filter Response | 5 ms |
| Channel-to-Channel Crosstalk Rejection | 30 dB minimum |
| External Power Supply | 18–30 VDC (24 VDC nominal) |
| External Power Consumption | 125 mA maximum @ 24 VDC |
| Backplane Current Consumption | 50 mA maximum @ 5 VDC |
| Isolation | 250 VAC field side to logic side; 1500 VAC for 1 minute |
| Output Default Behavior | Configurable hold last state or user-defined default value |
| Diagnostic Functions | Field power monitoring and module status diagnostics |
| LED Indicators | OK LED, Field Power (FLD PWR) LED |
| Installation Location | VersaMax I/O carrier |
| Compatible Systems | GE Fanuc / Emerson VersaMax PLC and Distributed I/O systems |
| Carrier Requirement | Requires IC200CHSxxx series carrier base |
| Mounting Method | DIN rail mounting |
| Operating Temperature | 0°C to +60°C (32°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5–95% RH (non-condensing) |
| Dimensions (H × W × D) | Approx. 110 × 66.8 × 50 mm (4.33 × 2.63 × 1.97 in.) |
| Weight | Approx. 0.17 kg (0.38 lb) |
| Hardware Revision | F |
| Product Status | Legacy Product |
| Warranty | 12 Months |
FAQ
FAQ
Q1: What is the GE Fanuc IC200ALG430F used for?
The IC200ALG430F is used in VersaMax PLC systems to process analog current signals. It can read signals from field transmitters and provide 4–20 mA control outputs for actuators, valves, and other analog devices.
Q2: How many analog channels does the IC200ALG430F provide?
The module provides four analog current input channels and two analog current output channels, giving a total of six analog channels in one module.
Q3: What signal range does the IC200ALG430F support?
The module supports the standard industrial 4–20 mA current loop signal for both input and output operations.
Q4: Does the IC200ALG430F require an external power supply?
Yes. The analog output section requires an external 18–30 VDC power supply (24 VDC nominal) to generate current output signals.
Q5: What is the resolution of the IC200ALG430F?
The module uses a 12-bit analog converter, providing precise conversion for both input and output current signals.
Q6: What type of devices can be connected to the IC200ALG430F?
The module can connect to industrial devices such as pressure transmitters, flow meters, level sensors, temperature transmitters with current output, control valves, and other 4–20 mA instruments.
Q7: What does the “F” revision indicate?
The “F” suffix identifies the hardware revision level of the IC200ALG430 analog mixed module. Revision F includes manufacturing improvements while maintaining compatibility with VersaMax systems.
Q8: What should be checked before replacing an IC200ALG430F module?
Before replacement, verify the VersaMax carrier compatibility, 4–20 mA loop wiring, external 24 VDC supply, channel configuration, PLC hardware settings, and analog scaling parameters to ensure correct operation after installation.
