Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation) |
| Product Model | IC200MDD841-GF |
| Product Type | VersaMax Mixed Discrete / High-Speed Counter Module |
| Series | VersaMax PLC |
| Function | Combines 24 VDC digital inputs, transistor outputs, and high-speed counter functions in one module |
| Module Type | Mixed Discrete I/O with HSC/PWM/Pulse Train Capability |
| Digital Inputs | 20 points, 24 VDC Positive Logic |
| Digital Outputs | 12 points, 24 VDC Positive Logic Transistor Outputs |
| Output Current Rating | 0.5 A maximum per output point |
| High-Speed Counter Channels | 4 channels (Type A high-speed counters) |
| High-Speed Counter Frequency | Up to 80 kHz |
| Counter Input Type | 24 VDC positive logic pulse input |
| Counter Functions | Up counting, down counting, up/down counting, frequency measurement |
| PWM Function | Supported |
| Pulse Train Output Function | Supported |
| High-Speed Output Channels | Configurable through module parameters |
| Output Protection | Short-circuit protection |
| Output Voltage Range | 10–30 VDC |
| Input Voltage Range | 18–30 VDC nominal 24 VDC |
| Input Logic Type | Positive Logic |
| Isolation Voltage | 250 VAC field-to-logic isolation |
| Field Power Supply | External 24 VDC required |
| Backplane Current Consumption | Approx. 150 mA @ 5 VDC |
| Configuration Method | Software configurable through VersaMax PLC configuration tools |
| Compatible Software | VersaPro / Proficy Machine Edition |
| Compatible Systems | GE Fanuc VersaMax PLC and VersaMax I/O stations |
| Installation Method | DIN rail mounting through VersaMax carrier |
| LED Indicators | OK, FLD PWR, input/output status LEDs |
| Applications | Encoder feedback, velocity measurement, material handling, counting, pulse control, machine automation |
| Operating Temperature | 0°C to +60°C (32°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5–95% RH (non-condensing) |
| Dimensions (H × W × D) | Approx. 66.8 × 110 × 50 mm (2.63 × 4.33 × 1.97 in.) |
| Weight | Approx. 1.0 kg (2.2 lb) |
| Hardware Revision | GF |
| Revision Description | Manufacturing location change revision |
| Product Status | Legacy Product |
| Warranty | 12 Months |
FAQ
FAQ
Q1: What is the GE Fanuc IC200MDD841-GF used for?
The IC200MDD841-GF is used in VersaMax PLC systems for mixed digital I/O control and high-speed pulse processing applications such as counting, encoder feedback, and motion-related control.
Q2: How many inputs and outputs does the IC200MDD841-GF provide?
The module provides 20 digital inputs and 12 transistor outputs, all operating with 24 VDC positive logic signals.
Q3: What is the maximum counting frequency of the IC200MDD841-GF?
The high-speed counter function supports pulse input processing up to approximately 80 kHz for rapid signal counting applications.
Q4: Can the IC200MDD841-GF be used with encoders?
Yes. The module supports high-speed pulse inputs and can be configured for encoder feedback, speed measurement, and position-related applications.
Q5: What output functions are supported by the IC200MDD841-GF?
The module supports standard transistor outputs as well as configurable high-speed counter outputs, PWM outputs, and pulse train outputs.
Q6: What voltage do the inputs and outputs use?
The module uses 24 VDC positive logic signals. The outputs can provide up to 0.5 A per point for compatible DC loads.
Q7: Which PLC systems are compatible with the IC200MDD841-GF?
The IC200MDD841-GF is designed for GE Fanuc VersaMax PLC systems and VersaMax I/O stations using compatible carriers.
Q8: What should be checked before replacing an IC200MDD841-GF module?
Before replacement, verify the VersaMax carrier compatibility, 24 VDC field wiring, output load requirements, high-speed counter configuration, PLC hardware settings, and module revision to ensure correct operation.
