Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC200MDL243 |
| Product Type | Discrete Input Module for GE VersaMax PLC |
| Number of Inputs | 16 discrete inputs |
| Input Voltage | 24 V DC nominal |
| Input Voltage Range | 18–30 V DC |
| Input Type | Positive logic (sourcing) |
| Input Current | Approx. 7 mA per point at 24 V DC |
| Response Time | Typical 1 ms |
| Isolation | Group-to-backplane isolation |
| Mounting | DIN rail mounting (VersaMax I/O base) |
| Operating Temperature | 0 °C to +60 °C |
| Status Indicators | Individual LEDs for each input point |
| Dimensions | Approx. 3.0 cm × 8.0 cm × 6.0 cm |
| Weight | Approx. 0.18 kg |
FAQ
FAQ
Q1: What is the IC200MDL243 used for?
It is a 24 V DC discrete input module used to monitor field devices such as switches and sensors in VersaMax PLC systems.
Q2: How many input points are available?
The module provides 16 discrete input points.
Q3: What input voltage does it support?
It supports a nominal 24 V DC input with an operating range of 18–30 V DC.
Q4: What type of input logic does it use?
It uses positive logic (sourcing) inputs.
Q5: What is the typical response time?
The typical input response time is approximately 1 millisecond.
Q6: Is electrical isolation provided?
Yes, it includes group-to-backplane isolation.
Q7: What are the physical dimensions and weight?
The module measures approximately 3.0 cm × 8.0 cm × 6.0 cm and weighs about 0.18 kg.
Q8: Are there LED indicators for status monitoring?
Yes, each input point has an individual LED status indicator.
