Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | Analog Input Module |
| Input Type | Current Input |
| Number of Channels | 6 Channels |
| Input Voltage Range | -10 V to +10 V |
| Input Current Range | 4 to 20 mA |
| Resolution | Voltage: 312.5 μV / LSB Current: 0.5 μA / LSB |
| Accuracy | Voltage: ±0.01% FS, ±0.02% Reading Current: ±0.05% FS, ±0.1% Reading |
| Input Impedance | >10 MΩ (with 0.47 µF capacitor in series) |
| Response Time | 0.1%: 67 ms; 0.5%: 51 ms; 1.0%: 42 ms; 5.0%: 30 ms |
| A/D Conversion Type | 16-bit Successive Approximation |
| Channel Isolation | Two groups of four channels isolated |
| Filter Function | Notch filter supported with configurable frequencies |
| Internal Power | 0.8 A @ 5V |
| Dimensions (W x H x D) | 224.4 mm x 88.9 mm x 100 mm |
| Weight | 1.8 kg |
| Connector Type | Terminal block with 20 screws (included) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of signal does the IC660BBA026 support?
A1: It supports 4 to 20 mA current input signals.
Q2: How many analog input channels are available on the IC660BBA026?
A2: It provides 6 analog input channels.
Q3: Does this module support voltage input?
A3: No, the IC660BBA026 is strictly for current input signals.
Q4: What is the resolution of the input signal?
A4: For current input, the resolution is 0.5 μA per LSB.
Q5: What is the typical response time of the module?
A5: The response time is 67 ms for 0.1% signal change.
Q6: Are the input channels isolated from each other?
A6: The 6 channels are divided into two isolated groups of four.
Q7: What type of A/D converter is used in this module?
A7: It uses a 16-bit successive approximation A/D converter.
Q8: What are the physical dimensions and weight of the module?
A8: The dimensions are 224.4 x 88.9 x 100 mm, and the weight is 1.8 kg.
