Technical Specifications
| Parameter | Specification |
|---|---|
| Model | GE IC660TBA021 |
| Type | Terminal Assembly |
| Function | Provides the connection interface between field devices and I/O modules |
| Terminal Type | Screw-type terminals |
| Number of Terminals | 24 terminals |
| Terminal Material | Tin-plated copper |
| Wire Size Range | 14–22 AWG |
| Voltage Rating | Up to 125 V AC/DC |
| Current Rating | 2 A per terminal |
| Insulation Resistance | >100 MΩ at 500 V DC |
| Dielectric Strength | 1500 V AC for 1 minute |
| Mounting Type | DIN rail or panel mounting |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5% to 95% non-condensing |
| Compatibility | GE Genius I/O blocks and related modules |
| Enclosure Material | Industrial-grade ABS plastic |
| Color | Black |
| Dimensions | 222.4 x 88.9 x 100 mm |
| Weight | 1.8 kg |
FAQ
FAQ
Q1: What is the main function of the GE IC660TBA021 Terminal Assembly?
A1: The IC660TBA021 serves as a terminal connection interface between field devices and GE I/O modules, enabling secure and organized wiring for industrial control systems.
Q2: What type of terminals does this assembly use?
A2: It uses screw-type terminals, which provide reliable mechanical and electrical connections suitable for industrial environments.
Q3: What wire sizes can be connected to the IC660TBA021?
A3: The terminal assembly supports wire sizes from 14 to 22 AWG, allowing flexibility for various wiring standards and field devices.
Q4: Is the IC660TBA021 compatible with other GE modules?
A4: Yes, it is fully compatible with GE Genius I/O blocks and related control modules, ensuring seamless integration within GE automation systems.
Q5: How does the IC660TBA021 ensure electrical insulation and safety?
A5: It features high insulation resistance and a dielectric strength of 1500 V AC for one minute, providing excellent protection against electrical faults.
Q6: What mounting options are available for this terminal assembly?
A6: The IC660TBA021 can be easily installed using either DIN rail or panel mounting, offering flexibility in control cabinet layouts.
Q7: Can this terminal assembly operate in harsh industrial environments?
A7: Yes, it is designed with an industrial-grade ABS enclosure and can operate reliably in temperatures from 0°C to 60°C and humidity up to 95%.
Q8: Does the IC660TBA021 require any special maintenance?
A8: Maintenance is minimal—periodic inspection of screw connections and terminal cleanliness is recommended to ensure consistent electrical contact and performance.
