Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC670CHS001 |
| Product Type | I/O Carrier / Terminal Block Module for GE Fanuc Field Control PLC Systems |
| Series | Field Control I/O family (GE Fanuc / Emerson Automation) |
| Function | Provides a connection and base for I/O modules, with barrier-style terminals for field wiring |
| Number of Terminals | 37 screw terminals |
| Terminal Wiring Size | AWG #14 (2.1 mm²) to AWG #22 (0.35 mm²); up to two wires per terminal |
| Tightening Torque | ~8 in-lb recommended |
| Isolation Rating | 90 °C insulation class |
| Hot-Swap Support | Yes — when used with compatible BIU firmware v2.1 or higher (non-hazardous locations) |
| Compatible Modules | Works with Field I/O modules suffix J or higher and IC670CBL001 cable |
| Mounting Type | DIN rail or panel mount (horizontal orientation) |
| Backplane Connectivity | Provides backplane connectors for I/O module communication |
| Application | Industrial automation signal termination and module support |
| Dimensions | ~17.8 cm × 10.2 cm × 7.6 cm (varies by version) |
| Weight | ~1.8 kg (varies by version) |
| Operating Environment | Industrial automation environments (typical PLC ambient) |
FAQ
FAQ
Q1: What is the IC670CHS001?
It is an I/O carrier base module used as a wiring terminal and support base for Field Control I/O modules in GE Fanuc PLC systems.
Q2: How many terminals does the IC670CHS001 have?
It has 37 barrier-style screw terminals for field wiring connections.
Q3: What wire sizes are supported on the terminals?
Terminals accept AWG #14 to AWG #22 wire, with up to two wires per terminal.
Q4: Does this chassis support hot-swapping of modules?
Yes — hot-swap capability is supported when paired with Bus Interface Units (BIUs) having firmware version 2.1 or higher (in non-hazardous areas).
Q5: What kind of modules can be installed on it?
It supports compatible Field I/O modules (discrete, analog, etc.) with catalogue suffix J or higher.
Q6: How is the IC670CHS001 mounted?
It can be mounted horizontally on a DIN rail or panel mount, depending on installation needs.
Q7: What are the approximate dimensions and weight?
The module is roughly 17.8 cm × 10.2 cm × 7.6 cm and weighs about 1.8 kg (actual values may vary by version).
Q8: What does the module provide besides wiring terminals?
In addition to field wiring terminals, it provides backplane connectors that enable communication between connected I/O modules.
