Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC693ACC302 |
| Manufacturer | GE (General Electric) |
| Product Type | Auxiliary Battery Module |
| Series | GE Fanuc Series 90-30 |
| Function | Provides backup power for CPU memory and real-time clock |
| Battery Type | Lithium battery pack |
| Nominal Voltage | 3.6 VDC |
| Capacity | 5.8 Ah |
| Battery Chemistry | Lithium Thionyl Chloride (Li-SOCl₂) |
| Rechargeability | Non-rechargeable |
| Connection Type | Plug-in cable connector |
| Compatibility | Series 90-30 CPUs and expansion units |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Mounting Type | Internal module bay connection |
| Safety Standards | UL, CE, and CSA certified |
| Application | Memory retention and system data preservation during power loss |
| Dimensions | 145.1 x 65 x 39.9 mm |
| Weight | 0.29 kg |
FAQ
FAQ
Q1: What is the main purpose of the GE IC693ACC302 Auxiliary Battery Module?
The IC693ACC302 provides backup power for CPU memory and the real-time clock in GE Fanuc Series 90-30 controllers, ensuring critical data is preserved when main power is lost.
Q2: What type of battery chemistry does the IC693ACC302 use?
It utilizes Lithium Thionyl Chloride (Li-SOCl₂) chemistry, offering high energy density, stable performance, and long service life under industrial conditions.
Q3: Is the IC693ACC302 battery rechargeable?
No, this is a non-rechargeable lithium battery module. Once depleted, it must be replaced with a new unit to maintain proper system backup capability.
Q4: How is the battery module connected to the system?
The IC693ACC302 connects directly to the CPU through a plug-in cable, enabling quick and reliable installation without additional hardware.
Q5: Which GE controllers are compatible with the IC693ACC302?
It is compatible with the GE Fanuc Series 90-30 CPUs, including models such as IC693CPU311, IC693CPU350, and other units that support auxiliary power connections.
Q6: What environmental conditions can the IC693ACC302 operate in?
The module operates efficiently within a temperature range of 0°C to +60°C and humidity levels between 5% and 95% non-condensing.
Q7: How should the IC693ACC302 be stored when not in use?
It should be stored in a cool, dry location between -40°C and +85°C to maintain battery integrity and prevent premature capacity loss.
Q8: How often should the IC693ACC302 be replaced?
Replacement is typically recommended once per year or when the CPU signals a low battery condition to prevent the risk of memory data loss.
