Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation) |
| Product Model | IC693ACC310A |
| Product Type | Blank Filler Module |
| Series | Series 90-30 PLC |
| Function | Covers unused slots in the PLC baseplate to protect the backplane and maintain proper airflow |
| Module Type | Passive (Non-electrical) |
| Electrical Function | None |
| Installation Location | Any unused slot in a Series 90-30 baseplate |
| Compatible Baseplates | All GE Fanuc Series 90-30 CPU and Expansion Baseplates |
| Compatible Systems | GE Fanuc / Emerson Series 90-30 PLC |
| Backplane Connection | No electrical connection |
| Cooling Function | Maintains proper airflow through the PLC rack |
| Protection Function | Prevents dust, debris, and accidental contact with unused backplane connectors |
| Material | Industrial-grade molded plastic |
| Mounting Method | Slides directly into an unused baseplate slot |
| Removal Method | Manual removal without tools |
| Maintenance | No maintenance required |
| Operating Temperature | 0°C to +60°C (32°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5–95% RH (non-condensing) |
| Dimensions (H × W × D) | Approx. 140 × 130 × 40 mm (5.51 × 5.12 × 1.57 in.) |
| Weight | Approx. 0.10 kg (0.22 lb) |
| Hardware Revision | A |
| Product Status | Legacy / Discontinued Product |
| Warranty | 12 Months |
FAQ
FAQ
Q1: What is the GE Fanuc IC693ACC310A used for?
The IC693ACC310A is used to fill empty slots in a Series 90-30 PLC baseplate. It protects unused backplane connectors while maintaining proper airflow and helping keep the PLC enclosure clean.
Q2: Does the IC693ACC310A perform any electrical or control functions?
No. The IC693ACC310A is a passive filler module. It contains no electronic components, performs no I/O processing, and does not communicate with the PLC CPU. Its purpose is purely mechanical and protective.
Q3: Which PLC systems are compatible with the IC693ACC310A?
The module is designed specifically for GE Fanuc Series 90-30 PLC systems and can be installed in any unused slot on compatible CPU or expansion baseplates.
Q4: Why should unused PLC slots be filled?
Leaving slots open can allow dust, dirt, and debris to enter the rack and may disrupt the designed airflow used to cool installed modules. Using the IC693ACC310A helps maintain reliable system operation.
Q5: Is the IC693ACC310A easy to install?
Yes. The module slides directly into an unused Series 90-30 baseplate slot and can be installed or removed quickly without special tools.
Q6: Does the IC693ACC310A require power or configuration?
No. Since it is a passive mechanical accessory, the module does not require electrical power, PLC configuration, or programming.
Q7: What does the “A” revision indicate?
The “A” suffix identifies the hardware revision of the filler module. As the module has no active electronics, revision changes generally relate to manufacturing or mechanical improvements while maintaining full compatibility with Series 90-30 baseplates.
Q8: What should be checked before installing an IC693ACC310A?
Before installation, verify that the target slot is unused, ensure the baseplate is compatible with the Series 90-30 platform, inspect the backplane connector for damage or contamination, and confirm the filler module is securely seated after installation.
