Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC694CHS392 |
| Product Type | Serial Expansion I/O Backplane |
| PLC Series | RX3i PACSystems |
| Number of Slots | 10 |
| Connector Type | 25‑pin female D‑sub |
| Expansion Cable Length | Up to 15 m / 50 ft |
| Internal Power Consumption | 150 mA @ 5 V DC |
| Hot Swap Capability | Not supported |
| Mounting Type | Rack/panel mounted |
| Operating Temperature | Typical industrial range (0 °C to 60 °C) |
| Weight | ~920 g (~2.03 lb) |
| Dimensions (WxHxD) | ~17.44″ × 5.12″ × 5.59″ (443 × 130 × 142 mm) |
FAQ
FAQ
Q1: What is IC694CHS392 used for?
It is a 10‑slot serial expansion baseplate for expanding I/O in RX3i PACSystems PLC installations.
Q2: How many modules can be installed on IC694CHS392?
Up to ten slots are available for standard I/O or option modules.
Q3: Does IC694CHS392 support hot‑swapping of modules?
No, modules must be installed or removed only with power off.
Q4: What cable length can be used between backplanes?
Expansion cables up to about 15 m (50 ft) are supported.
Q5: Which connector does this backplane use for expansion?
It uses a 25‑pin female D‑sub expansion connector.
Q6: Is a power supply included with the baseplate?
No, a compatible RX3i power supply module (installed in slot 0) is required.
Q7: What power does the backplane consume?
It draws about 150 mA at 5 V DC internally.
Q8: Which PLC series is IC694CHS392 compatible with?
It is designed for GE/Emerson RX3i PACSystems controllers.
