Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Yokogawa SBD4D‑06 Terminal Board |
| Product Type | Digital Terminal Board |
| Channels | 16 channels × 1 unit |
| Operating Voltage | 24 V DC |
| Current Load | Up to 5 A |
| Mounting Type | DIN rail mount |
| Redundancy Support | Single and dual‑redundant configurations |
| Certifications | ISA Standard G3 (no explosion protection) |
| Operating Temperature Range | –20 °C to +60 °C |
| Weight (Approx.) | ~0.3 kg |
| Dimensions (Approx.) | ~130 mm × 50 mm × 30 mm |
| Application | For use with SDV144 / SDV541 and similar safety I/O systems |
FAQ
FAQ
Q1: What is the function of the SBD4D‑06 board?
It is a digital terminal board that organizes and connects field signals in safety PLC systems.
Q2: How many channels are provided by this terminal board?
It provides 16 digital channels.
Q3: What voltage and current does it support?
Designed for 24 V DC systems with up to 5 A per board.
Q4: How is the SBD4D‑06 mounted?
It mounts on a standard DIN rail.
Q5: Does the terminal board support redundancy?
Yes, it supports both single and dual‑redundant configurations.
Q6: What safety standards does this board meet?
It complies with ISA Standard G3 (without explosion protection).
Q7: What is the operating temperature range?
It operates from –20 °C to +60 °C.
Q8: What are the approximate size and weight?
Approximately 130 mm × 50 mm × 30 mm and about 0.3 kg.
