Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC697CHS783 |
| Product Type | VME Integrator Rack |
| Compatible PLC Series | GE Fanuc Series 90‑70 PLCs |
| Function | Front‑mount 17‑slot VME rack for PLC and third‑party VME modules |
| Number of Slots | 17 single‑width (8 double‑width) plus power supply slot |
| Mounting Options | Front rack mount (19‑inch) or rear panel mount (10‑inch deep enclosure) |
| Internal Power Usage | ~3.3 A @ 5 V DC; optional auxiliary supply support |
| Backplane Interface | 17‑slot VME backplane, 0.8‑inch slot spacing |
| Supported Modules | GE IC697 PLC modules and 3rd‑party VME modules with 0.8‑inch spacing |
| Indicators | N/A (rack chassis only) |
| Operating Temperature | Typical industrial range (0 °C to 60 °C) |
| Operating Humidity | 5 % to 95 % non‑condensing |
| Dimensions (Approx.) | 283 mm × 483 mm × 191 mm |
| Weight (Approx.) | ~0.5 kg |
FAQ
FAQ
Q1: What is IC697CHS783 used for?
It is a front‑mount VME integrator rack to house GE Fanuc Series 90‑70 PLC and compatible VME modules.
Q2: How many module slots does this rack provide?
It has 17 slots (single‑width) or 8 double‑width equivalents plus a slot for the power supply.
Q3: Which PLC systems is it compatible with?
GE Fanuc Series 90‑70 PLC systems.
Q4: Can it mount third‑party modules?
Yes, VME modules meeting the 0.8‑inch spacing standard can be installed.
Q5: How can this rack be mounted?
It can be installed in a 19‑inch standard rack or rear‑panel mount in a 10‑inch‑deep enclosure.
Q6: What are the dimensions of IC697CHS783?
Approximately 283 mm × 483 mm × 191 mm.
Q7: What internal power does the rack use?
It draws about 3.3 A @ 5 V DC from the internal supply and supports additional auxiliary supply configurations.
Q8: What environment is this rack designed for?
Industrial environments with temperature up to ~60 °C and standard humidity levels.
