Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC697CPU781 |
| Product Type | Central Processing Unit (CPU) Module for GE Fanuc Series 90-70 PLC |
| Processor | Intel 80386EX, 25 MHz (32-bit) |
| Execution Speed | Approx. 0.2 µs per Boolean instruction |
| Memory | Up to 512 KB user memory (expandable) |
| I/O Capacity | Up to 12,000 discrete I/O points and up to 8,000 analog I/O points |
| Communication Port | RS-485 serial port (SNP protocol) |
| Redundancy Support | Supports hot standby CPU redundancy |
| Battery Backup | Lithium battery for RAM and clock retention |
| Power Requirement | 5 V DC supplied from backplane |
| Current Consumption | Approx. 1.5 A @ 5 V DC |
| Operating Temperature | 0 °C to +60 °C |
| Mounting | Single CPU slot in Series 90-70 rack |
| Dimensions | Approx. 3.5 cm × 13 cm × 13.5 cm |
| Weight | Approx. 0.32 kg |
FAQ
FAQ
Q1: What is the IC697CPU781 used for?
It serves as the main processor in a Series 90-70 PLC system, executing control programs and coordinating I/O operations.
Q2: What processor does this module use?
It uses a 25 MHz Intel 80386EX 32-bit processor designed for industrial control tasks.
Q3: How fast is the instruction execution?
The Boolean execution speed is approximately 0.2 microseconds per instruction.
Q4: What is the maximum I/O capacity supported?
The CPU supports up to 12,000 discrete I/O and up to 8,000 analog I/O points.
Q5: Does the IC697CPU781 support redundancy?
Yes, it supports hot standby redundancy for high-availability applications.
Q6: What communication interface is built in?
It includes an RS-485 serial port using the SNP protocol for programming and communication.
Q7: What are the physical size and weight?
The module measures approximately 3.5 cm × 13 cm × 13.5 cm and weighs about 0.32 kg.
Q8: Is memory retained during power loss?
Yes, a built-in lithium battery maintains user memory and the real-time clock during power interruptions.
