Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC697GDS701 |
| Product Type | 24 V DC Power Supply Module for GE Fanuc Series 90-70 PLC |
| Input Voltage | 24 V DC nominal |
| Input Voltage Range | 18–30 V DC |
| Output Voltage | 5 V DC regulated (backplane power) |
| Output Current | Up to 20 A |
| Power Capacity | Approx. 100 W |
| Protection Features | Overvoltage, overcurrent, and short-circuit protection |
| Status Indicators | Front-panel LEDs for power and fault status |
| Cooling Method | Convection cooled |
| Mounting | Installs in the designated power supply slot of Series 90-70 rack |
| Operating Temperature | 0 °C to +60 °C |
| Dimensions | Approx. 10.5 cm × 15.2 cm × 25.4 cm |
| Weight | Approx. 1.6 kg |
FAQ
FAQ
Q1: What is the IC697GDS701 used for?
It provides regulated backplane power to GE Fanuc Series 90-70 PLC systems from a 24 V DC input source.
Q2: What input voltage range does this module support?
It supports a 24 V DC nominal input with a range of 18–30 V DC.
Q3: What output voltage does the IC697GDS701 provide?
It supplies 5 V DC regulated output to power the CPU and I/O modules.
Q4: How much current can the module deliver?
It can deliver up to 20 A of output current.
Q5: Does it include protection features?
Yes, it protects against overvoltage, overcurrent, and short circuits.
Q6: How is the module cooled?
The module is convection-cooled, requiring no fan.
Q7: What are the physical dimensions and weight?
The module measures approximately 10.5 cm × 15.2 cm × 25.4 cm and weighs about 1.6 kg.
Q8: Where is the IC697GDS701 installed in the system?
It is mounted in the designated power supply slot of a Series 90-70 PLC rack.
