Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC697MDL752 |
| Product Type | Analog Output Module for GE Fanuc Series 90-70 PLC |
| Number of Channels | 16 analog outputs |
| Output Signal Type | ±10 V DC, 0–20 mA, 4–20 mA (configurable per channel) |
| Resolution | 14-bit D/A conversion |
| Load Impedance | Voltage output: ≥ 5 kΩ; Current output: 500 Ω maximum |
| Update Rate | 2.5 ms per channel typical |
| Accuracy | ±0.05% of full scale |
| Isolation | Channel-to-backplane isolation |
| Mounting | Fits standard I/O slot in Series 90-70 rack |
| Operating Temperature | 0 °C to +60 °C |
| Status Indicators | LEDs for output status and diagnostics |
| Dimensions | Approx. 3.5 cm × 13 cm × 13.5 cm |
| Weight | Approx. 0.43 kg |
FAQ
FAQ
Q1: What is the IC697MDL752 used for?
It is a high-density analog output module for GE Fanuc Series 90-70 PLCs, designed to control multiple analog field devices.
Q2: How many output channels does it provide?
The module provides 16 analog output channels.
Q3: What types of output signals are supported?
It supports ±10 V DC, 0–20 mA, and 4–20 mA outputs, configurable per channel.
Q4: What is the resolution of the outputs?
It offers 14-bit digital-to-analog conversion for precise control.
Q5: What is the typical update rate?
Each channel updates approximately every 2.5 milliseconds.
Q6: Does the module provide electrical isolation?
Yes, each output channel is isolated from the backplane for protection and noise reduction.
Q7: What are the physical dimensions and weight?
The module measures approximately 3.5 cm × 13 cm × 13.5 cm and weighs about 0.43 kg.
Q8: Are there status indicators on the module?
Yes, front-panel LEDs indicate output status and diagnostic conditions.
