Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC754VGL12CTD |
| Product Type | Industrial Graphic Operator Interface (HMI) Panel |
| Display Size | 12.1-inch diagonal color LCD |
| Resolution | 800 × 600 pixels (SVGA) |
| Touchscreen | Resistive touch input |
| Graphics Capability | Full color bitmap display with graphical object support |
| Processor | Embedded industrial CPU |
| Memory | Internal flash and RAM for application storage |
| Communication Ports | Ethernet 10/100 Mbps; Serial (RS-232/RS-485) |
| Supported Protocols | Modbus RTU/TCP, OPC, GE Fanuc PLC protocols |
| Power Supply | 12/24 V DC |
| Power Consumption | Approx. 30–40 W |
| Operating Temperature | 0 °C to +50 °C |
| Mounting | Panel mount |
| Protection Rating | NEMA 4/12/13 front panel (dust and splash resistant) |
| Dimensions (Panel Cutout) | Approx. 305 × 230 × 60 mm |
| Weight | Approx. 2.8 kg |
FAQ
FAQ
Q1: What is the IC754VGL12CTD used for?
It is a 12.1-inch graphic operator interface (HMI) used to display process information and interact with industrial control systems.
Q2: What kind of display does the panel have?
It features a 12.1-inch color LCD with an 800×600 SVGA resolution and resistive touch input.
Q3: What communication interfaces does it support?
It supports Ethernet (10/100 Mbps) and serial communication (RS-232/RS-485) for PLC and device connectivity.
Q4: What protocols are supported?
Common supported protocols include Modbus RTU/TCP, OPC, and GE Fanuc PLC protocols.
Q5: What power supply is required?
The panel operates on 12/24 V DC power.
Q6: Is the panel suitable for industrial environments?
Yes, the front panel is rated NEMA 4/12/13 for protection against dust and splash.
Q7: What are the physical dimensions?
The panel cutout size is approximately 305 × 230 × 60 mm.
Q8: What is the typical operating temperature range?
It generally operates reliably between 0 °C and +50 °C.
Tags
Packing & Delivery
We will use wear-resistant cartons to seal the boxes, and take photos for your confirmation before sealing. We will pack the boxes only after confirmation.
For express delivery, we will use DHL, UPS, TNT, FedEx and EMS.
Please rest assured that we have a deep cooperation with express delivery companies and can ensure that your goods are delivered to you in good condition.
