Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | IC755CSW07CDA |
| Manufacturer | GE Fanuc / Emerson Automation |
| Series | QuickPanel+ |
| Product Type | HMI (Human Machine Interface) / Operator Terminal |
| Display | 7-inch TFT LCD, 800 × 480 resolution |
| Touch Type | Projected capacitive multi-touch |
| Processor | Freescale i.MX535 ARM Cortex-A8 @ 1 GHz |
| Memory | 512 MB DDR2 SDRAM / 256 MB NAND Flash / 512 KB SRAM |
| Operating System | Windows Embedded Compact 7 |
| Communication Ports | 1 × Ethernet (10/100 Mbps), 1 × RS-232, USB ports |
| Power Supply | 24 VDC (approx. 15 W max) |
| Protection Rating | IP65 (front panel, typical) |
| Programming Software | Proficy Machine Edition |
| Mounting Type | Panel mount |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 60°C |
| Dimensions (H × W × D) | ≈ 180 × 130 × 40 mm |
| Weight | ≈ 0.8–2.0 kg (varies by revision/packaging) |
FAQ
FAQ
Q1: What is IC755CSW07CDA used for?
It is used as an industrial HMI panel for monitoring and controlling machines and processes.
Q2: What screen does it have?
A 7-inch color TFT touchscreen (800×480 resolution) with capacitive multi-touch.
Q3: What PLC systems does it support?
It works with GE PACSystems, Series 90-30/70, and third-party PLCs via standard protocols.
Q4: What operating system is used?
It runs Windows Embedded Compact 7.
Q5: What communication ports are available?
It includes Ethernet, RS-232, and USB interfaces.
Q6: What is the power requirement?
It operates on 24 VDC power supply (about 15 W max).
Q7: Is it suitable for harsh environments?
Yes, it has an IP65-rated front panel for industrial environments.
Q8: What are its dimensions and weight?
Approximately 180 × 130 × 40 mm, weight about 0.8–2.0 kg depending on configuration.
