Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | IS200AEADH1ACA |
| Product Type | Analog Output Module (Mark VIe / Speedtronic) |
| Series | IS200 Series I/O |
| Output Channels | 8 independent analog outputs |
| Output Signal Types | 4–20 mA DC; 0–10 V DC (selectable per channel) |
| Load Resistance | 4–20 mA: 0–600 Ω; 0–10 V: ≥1 kΩ |
| Accuracy | ±0.1 % of full scale |
| Response Time | ≤1 ms |
| Signal Drift | ≤0.01 % of full scale per year |
| Isolation | 2500 VAC galvanic isolation between channels and backplane |
| Power Supply | 24 V DC ±10 %; ≤8 W at full load |
| Protection | Short‑circuit, over‑voltage (≥30 V DC), reverse polarity |
| Operating Temperature | 0 °C to +60 °C |
| Humidity | 5 % to 95 % non‑condensing |
| Mounting | Mark VIe backplane rack |
| Dimensions (approx.) | 160 mm × 100 mm × 35 mm |
| Weight | ~0.4 kg |
| Status | Industrial analog output module for turbine/process control |
FAQ
FAQ
Q1. What is the main function of the IS200AEADH1ACA module?
It converts digital commands from a controller into precise analog signals (typically 4–20 mA or 0–10 V) for actuators such as valves and regulators.
Q2. How many analog outputs does this module support?
It supports 8 independent analog output channels.
Q3. What types of output signals can it generate?
Each channel can output either 4–20 mA DC or 0–10 V DC, selectable in the system configuration.
Q4. What level of accuracy does the module achieve?
It has high precision with an accuracy of about ±0.1 % of full scale.
Q5. What electrical protections are built into the module?
It includes short‑circuit protection, over‑voltage protection, and reverse polarity protection.
Q6. What is the operating temperature range?
The module is designed for industrial environments and operates between 0 °C and 60 °C.
Q7. How is the IS200AEADH1ACA mounted?
It is installed in a Mark VIe rack or backplane within a control cabinet.
Q8. What isolation features does this module provide?
It offers high galvanic isolation (2500 VAC) between the output channels and the backplane to protect against electrical noise and faults.
