Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IS200DAMAG1BCB |
| Manufacturer | General Electric |
| Series | Mark VI Speedtronic IS200 |
| Product Type | Gate Drive Amplifier / Interface Board |
| Functional Description | Printed circuit board that amplifies and interfaces gate drive signals between IGBT bridge legs and other control/driver modules in turbine control and drive systems. Works with upper and lower phase leg IGBTs and interfaces with the Bridge Personality Interface board. |
| Application | Used in Mark VI Speedtronic turbine control systems and low‑voltage 620 frame drive systems to manage power electronics gate signals. |
| Connectors | Multiple vertical connectors including a 12‑pin and a 6‑pin connector for IGBT and controller interfaces. |
| LED Indicators | Four LEDs (two yellow for IGBT “on” status, two green for IGBT “off” status). |
| PCB Coating | Standard protective PCB coating (normal assembly). |
| Operating Environment | Industrial turbine control cabinet rack conditions (typical Mark VI system environment). |
| Dimensions (L × W × H) | Approx. 160 mm × 160 mm × 120 mm (6.3″ × 6.3″ × 4.7″). |
| Weight | Approx. 0.8 kg (1.76 lbs). |
| Revision / Compatibility | Has multiple revisions; backwards compatible with earlier groups. |
| Country of Origin | United States (typical). |
FAQ
FAQ
Q1. What is IS200DAMAG1BCB?
IS200DAMAG1BCB is a gate drive amplifier and interface board used in GE Mark VI Speedtronic turbine and drive control systems to provide amplified gate command signals for IGBT power modules.
Q2. What does this board do?
It amplifies and conditions gate drive signals and interfaces them between the IGBT bridge legs (upper and lower) and the bridge personality interface, helping control power electronics behavior.
Q3. Which systems use this board?
It is used in GE Mark VI Speedtronic control systems, particularly those with 620 frame low‑voltage drive applications.
Q4. What connectors does it have?
It typically includes a 12‑pin vertical connector and a 6‑pin vertical connector for interfacing with IGBTs and controller logic.
Q5. What are the board dimensions?
The board’s approximate dimensions are 160 mm × 160 mm × 120 mm.
Q6. How much does it weigh?
It weighs approximately 0.8 kg.
Q7. What LEDs are on the board?
There are four LEDs: two yellow indicate IGBT “on” status and two green indicate IGBT “off” status.
Q8. Is IS200DAMAG1BCB still available?
This is a legacy Mark VI series board; GE may not actively manufacture it, but it is available through aftermarket and surplus parts suppliers.
