Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | GE IS200EGDMH1ADE |
| Manufacturer | General Electric (GE) |
| Series | EX2100 / Mark VI Excitation Control |
| Product Type | Exciter Field Ground Detector Module |
| Functional Role | Detects leakage resistance between generator field circuits and ground to support safe excitation operation. |
| Number of Channels | 12 channels for ground fault detection. |
| Input Range | 4–20 mA detector input span. |
| Technology | Surface mount technology. |
| Common Mode Voltage Range | ±5 V common‑mode input tolerance. |
| Maximum Lead Resistance | 15 Ω. |
| Analog Output | 0–20 mA analog signal output. |
| Operating Temperature | –30 °C to +65 °C. |
| Dimensions | Height 82.6 mm × Width 41.9 mm (typical board form factor). |
| Weight | ~0.35 kg (350 g). |
| Installation | Mounts in Exciter Power Backplane Rack (EPBP) of GE excitation control systems. |
| Compliance | Designed for industrial generator excitation field ground monitoring applications. |
FAQ
FAQ
Q1. What is the primary purpose of the GE IS200EGDMH1ADE?
It is a field ground detector module that senses leakage resistance to ground in generator field circuits to protect against insulation faults.
Q2. How many channels does this module support?
It supports 12 channels for ground fault detection.
Q3. What input signal range does the IS200EGDMH1ADE accept?
It accepts a 4–20 mA input span for ground fault sensing circuits.
Q4. What is the operating temperature range?
The module is rated for operation from –30 °C to +65 °C.
Q5. Where is this board mounted?
It is installed in the Exciter Power Backplane Rack (EPBP) within GE excitation control systems.
Q6. Does the IS200EGDMH1ADE output a diagnostic signal?
Yes, it outputs an analog 0–20 mA signal corresponding to detected ground fault conditions.
Q7. How heavy and large is this module?
The board weighs about 0.35 kg and has a height of ~82.6 mm and width ~41.9 mm.
Q8. Is this module suitable for industrial environments?
Yes, it is designed for use in industrial turbine generator excitation control environments.
