Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | IS200EISBH1AAA |
| Manufacturer | General Electric (GE) |
| Product Type | Exciter ISBus Communication Board |
| Series / System Compatibility | GE Mark VI / EX2100 turbine control and excitation system |
| Functional Role | Interfaces high‑speed exciter feedback signals between controller modules (M1, M2, C) and DSPX controller using ISBus and fiber‑optic links |
| Communication Interfaces | Fiber‑optic feedback ports; RS‑232C serial port for tool/keypad communication |
| Power Supply | 24 V DC logic supply |
| Mounting Type | Single‑slot, 3U high VME module |
| Supported Modules | Interfaces with M1, M2, C, DSPX and EDCF boards |
| Operating Temperature | –30 °C to +65 °C |
| Relative Humidity | 5 %–95 % non‑condensing (industrial tolerance) |
| Fiber‑Optic Ports | Six front‑panel fiber‑optic connectors |
| Reset Control | Accessible reset switch on front faceplate |
| PCB Protection | Conformal coating for industrial environments |
| Dimensions | Approx. 160 mm × 120 mm × 30 mm |
| Weight | Approx. 0.4 kg |
| Revision Count | Three revisions (A‑rated) |
| Country of Origin | USA (typical for GE Mark VI boards) |
FAQ
FAQ
Q1. What is the IS200EISBH1AAA?
It is an exciter ISBus communication board used in GE Mark VI/EX2100 systems to manage fiber‑optic and serial data exchange between controller modules.
Q2. What signals does this board interface?
It handles high‑speed exciter feedback signals via fiber‑optic ports and RS‑232C interfaces.
Q3. What communication protocols does it use?
It uses the proprietary ISBus protocol over fiber‑optic links and standard serial communications for diagnostics.
Q4. What controllers does it connect?
It connects M1, M2, C controllers and the DSPX controller in the Mark VI/EX2100 system.
Q5. What power does this board require?
It operates on a 24 V DC logic power supply.
Q6. What is the physical form factor of this board?
It is a single‑slot, 3U high VME module designed for installation in turbine control racks.
Q7. What is the operating environment?
It is rated for industrial use with an operating temperature range of about –30 °C to +65 °C and wide humidity tolerance.
Q8. What happens if this board fails?
Failure can interrupt exciter feedback communication, potentially affecting turbine excitation control and overall system stability.
