Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | IS200ERSDG1A Excitation Regulator Converter Board |
| Manufacturer | General Electric (GE) |
| Series / Product Line | EX2100 / EX2100e Excitation Control System |
| Module Type | Regulator Converter / Power Conversion Board |
| Primary Function | Converts DC/AC input to PWM-controlled DC output for exciter field and dynamic discharge in regulator systems |
| Power Conversion Method | PWM DC output via integrated IGBT inverter modules |
| IGBT Configuration | Six IGBTs in three-phase arrangement |
| Field Excitation Output | PWM DC for field excitation control |
| Dynamic Discharge Function | IGBT discharge of DC link capacitors to resistor |
| Input Power Sources | Rectified AC, DC from station battery, or both |
| Operating Temperature | Industrial range (typical) |
| Storage Temperature | Industrial range |
| Dimensions (approx.) | 15 × 10 × 4.62 cm (length × width × thickness) |
| Weight (approx.) | ~0.4 kg |
| Mounting | Backplane slot mount in EX2100 / EX2100e cabinet |
| Application Environment | Industrial excitation/regulator systems |
FAQ
FAQ
Q1. What is the IS200ERSDG1A used for?
It is a converter board in GE EX2100/EX2100e excitation control systems that generates controlled PWM DC output for field excitation and dynamic discharge functions.
Q2. Which systems is this board compatible with?
It is compatible with GE EX2100 and EX2100e Excitation Control System platforms.
Q3. How does the board generate excitation output?
It uses six IGBTs arranged in a three-phase inverter configuration to produce PWM DC output.
Q4. What is the dynamic discharge function?
One IGBT is dedicated to safely discharge DC link energy into an external resistor to prevent overvoltage.
Q5. What input power sources can it accept?
It can operate from rectified AC, DC from a station battery, or both.
Q6. What are the physical dimensions of the IS200ERSDG1A?
The approximate dimensions are 15 × 10 × 4.62 cm (length × width × thickness).
Q7. What is the approximate weight of the board?
The board weighs around 0.4 kg.
Q8. Does the board include any isolation?
Yes, the design includes isolation between power conversion circuits and control logic for safety.
Q9. Can the board be serviced while powered?
No, the system should be powered down before installing or removing the module for safety.
Q10. Is the IS200ERSDG1A still available?
Yes, it is available through industrial automation parts suppliers and surplus inventories.
