Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model Number | IS200JPDSG1ACB |
| Product Type | DC Power Distribution / Power Distribution Board |
| Series | Mark VIe Control System |
| Function | Distributes 28 V DC power to I/O modules and peripheral devices in turbine control systems |
| Compatible Systems | GE Mark VIe Distributed Control System |
| Input Voltage | 28 V DC (±10%) |
| Output Channels | 6 outputs via Mate‑N‑Lok connectors (2 A per channel typical) |
| Power Capacity | ~12 A continuous, 24 A peak (total distribution) |
| Protection | Poly‑fuse protection per output channel |
| LED Indicators | Power and status LEDs for diagnostics |
| Operating Temperature | -30 °C to +65 °C |
| Storage Temperature | -40 °C to +85 °C (industry typical) |
| Humidity | 5 % to 95 % non‑condensing |
| Mounting | DIN‑rail or sheet metal frame mounting within control cabinet |
| Dimensions (approx.) | 158.75 mm × 107.95 mm × 48 mm |
| Weight | ~0.6 kg |
| Certifications | UL 508, CE, CSA typical industrial certifications |
FAQ
FAQ
Q1. What is the IS200JPDSG1ACB module used for?
It distributes 28 V DC power to I/O packs and peripheral devices in GE Mark VIe turbine control systems.
Q2. Which control system is this board compatible with?
It is designed for use in GE’s Mark VIe distributed control system.
Q3. What input voltage does this board accept?
The board accepts 28 V DC input power within ±10 % range.
Q4. How many output channels does it provide?
It typically provides six DC output channels for power distribution.
Q5. What kind of protection does it have?
Each output channel includes poly‑fuse protection to guard against overloads.
Q6. What is its operating temperature range?
The module operates from -30 °C up to +65 °C.
Q7. Does this board include status indicators?
Yes, it includes LED indicators for power and diagnostic status.
Q8. What is the physical size and weight of the IS200JPDSG1ACB?
Its approximate footprint is 158.75 mm × 107.95 mm × 48 mm, and it weighs about 0.6 kg.
