Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | GE IS200TBAOH1CCB Analog Output Terminal Board |
| Module Type | Analog output terminal and field-connection board |
| Function | Routes and conditions analog output signals from the control system to field devices |
| Output Channels | Supports multiple current or voltage analog output channels depending on system configuration |
| Signal Types | Typically 0–20 mA, 4–20 mA, or voltage-based output depending on connected controller |
| Isolation | Channel-to-channel and channel-to-system isolation for noise reduction and protection |
| Connectors | Terminal blocks for convenient field wiring and quick maintenance |
| System Compatibility | Designed for GE Mark VI / Mark VIe and IS200 series control platforms |
| Operating Environment | Industrial-grade board for high-temperature and electrically noisy environments |
| Dimensions | 270 × 110 × 30 mm |
| Weight | 0.72 kg |
| Applications | Turbine control, process automation, actuator control, and analog signaling in industrial systems |
FAQ
FAQ
Q1: What is the main purpose of the IS200TBAOH1CCB terminal board?
A1: Its main role is to distribute and condition analog output signals generated by the controller so they can be accurately delivered to field instruments or actuators.
Q2: Does this board support multiple analog output types?
A2: Yes, it can handle both current-loop and voltage-based outputs, depending on how the associated controller channels are configured.
Q3: How does the board ensure reliable signal transmission?
A3: It includes filtering, isolation barriers, and stable grounding paths to maintain accuracy and prevent distortion from electrical noise.
Q4: Is the IS200TBAOH1CCB interchangeable with other TBAO series boards?
A4: It must match the system’s hardware revision, but within the same series, many boards share similar layouts, allowing controlled interchangeability.
Q5: How is field wiring handled on this board?
A5: It uses labeled terminal blocks that allow straightforward wiring and simplify maintenance, diagnostics, and signal tracing.
Q6: What type of isolation is provided?
A6: The board incorporates channel-to-channel and channel-to-ground electrical isolation to protect the control system from external disturbances.
Q7: Can this board be used in high-noise industrial environments?
A7: Yes, it is built with robust PCB layout strategies and shielding paths designed specifically for turbine halls, power plants, and heavy-industry settings.
Q8: Does replacing the board require recalibrating analog channels?
A8: Generally, no. As long as the replacement is the same model and revision, existing calibration data stored in the controller remains valid.
