Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | IS200TDBTH6ABC |
| Manufacturer | General Electric (GE) |
| Product Type | Discrete Input Terminal Board |
| Series | Mark VI Speedtronic Control System |
| Application | Turbine Control Signal Interface |
| Function | Interfaces field discrete input signals to the control system |
| Input Type | Dry contact / 24–125 VDC discrete signals |
| Input Channels | Multiple isolated discrete inputs (configuration dependent) |
| Signal Isolation | Optical isolation |
| Mounting Type | Rack-mounted |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 330 mm × 180 mm × 55 mm |
| Weight | Approx. 1.3 kg |
| Compliance | Industrial turbine control standards |
FAQ
FAQ
Q1. What is the purpose of the IS200TDBTH6ABC?
The IS200TDBTH6ABC serves as a discrete input terminal board in GE Mark VI turbine control systems.
Q2. What types of signals does this board handle?
It processes dry contact and DC discrete input signals from field devices.
Q3. Is the module compatible with all Mark VI systems?
It is designed for use within GE Mark VI Speedtronic control configurations.
Q4. Does the board provide signal isolation?
Yes, it uses optical isolation to protect the control system from field-side interference.
Q5. How is the board installed?
The unit is mounted directly inside the Mark VI control rack.
Q6. What is the supported operating temperature range?
The board operates between 0°C and 60°C under normal conditions.
Q7. What are the physical dimensions and weight of the module?
The unit measures approximately 330 mm × 180 mm × 55 mm and weighs about 1.3 kg.
Q8. Can it be used in both gas and steam turbine systems?
Yes, it supports discrete signal interfacing for both gas and steam turbine control applications.
