Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | IS200TREGH1BDC |
| Series | Mark VI Series |
| Type | Turbine Emergency Terminal Board |
| Function | Interface for turbine emergency trip signals |
| Mounting Type | Rack-mounted |
| Wiring Type | Screw terminal strip |
| Channels | Multi-channel signal support |
| Interface Type | Direct connection to controller modules |
| Operating Temperature | -30°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Redundancy | Supported |
| Redundant Power Input | Supported |
| Board Material | Industrial-grade copper-clad laminate |
| Dimensions | 178 x 330.2 x 43 mm |
| Weight | 0.907 kg |
FAQ
FAQ
Q1: What are the primary applications of the IS200TREGH1BDC?
A1: It is primarily used in gas and steam turbine control systems to handle emergency trip signal interfacing.
Q2: Does this module support redundancy?
A2: Yes, the IS200TREGH1BDC supports redundant I/O configurations for enhanced reliability.
Q3: Which controllers is it compatible with?
A3: It is compatible with GE Mark VI series controllers.
Q4: Is it hot-swappable?
A4: No, the module is not hot-swappable. Power must be off during installation or replacement.
Q5: What is the mounting method of this board?
A5: The IS200TREGH1BDC is designed for rack mounting within standard control cabinets.
Q6: Can it operate in high humidity environments?
A6: Yes, it supports 5% to 95% non-condensing humidity levels.
Q7: Does the module have overload or short-circuit protection?
A7: It does not feature built-in protection; external protection circuits are required.
Q8: What is the operating temperature range of the module?
A8: The operating temperature range is -30°C to +70°C, suitable for industrial conditions.
