Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | GE IS200TRPGH1BCC |
| Product Type | Thermocouple Terminal Board / Relay Interface Board |
| Series | GE Mark VI / IS200 series |
| Board Type | Terminal / Interface board for thermocouple or relay connections |
| Input Channels | Up to 16 thermocouple or signal terminals |
| Relay Contacts | Multiple relay contact points for control/signal wiring (details vary by configuration) |
| Voltage Rating | Terminal board supports standard 24 V DC field/control signals |
| Current Rating | Up to ~10 A (depends on contact and board design) |
| Operating Temperature | Approx. –20 °C to +70 °C (industrial environment) |
| Storage Temperature | Approx. –40 °C to +85 °C |
| Electrical Isolation | Isolation via terminal board wiring; grounded per system design |
| Connection Type | Screw or terminal block connectors for field sensor/relay wiring |
| Mounting Method | Panel or rack-mount within control cabinet |
| Dimensions | Approx. 330 mm × 102 mm × 48 mm (varies by board form factor) |
| Weight | Approx. 0.5 kg (varies by build) |
| Typical Application | Temperature signal termination and relay interfacing in turbine/industrial control systems |
FAQ
FAQ
Q1. What type of board is the IS200TRPGH1BCC?
It is a thermocouple terminal and relay interface board used for wiring and signal termination within GE Mark VI control systems.
Q2. How many channels does this board support?
It supports up to 16 terminal connections for thermocouples or field signals.
Q3. What is the purpose of this board in a control system?
It provides a robust connection point for thermocouple sensors and relays, simplifying wiring and improving signal integrity.
Q4. What voltage and current ratings does the board handle?
It handles standard control voltages (~24 V DC) with relay contact ratings up to about 10 A depending on configuration.
Q5. What is the typical operating temperature range?
It is designed to operate in industrial environments, typically from around –20 °C to +70 °C.
Q6. How is the IS200TRPGH1BCC installed?
The board is mounted within a control cabinet, often on a rack or panel, and wired to field sensors and relays.
Q7. Is it a standalone controller?
No — it is a terminal/relay interface board that works with other Mark VI/IS200 controllers and modules.
Q8. What applications typically use this board?
It is used in turbine protection, engine monitoring, and industrial automation where thermocouple temperature signals and relay outputs must be wired and distributed reliably.
