Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | IS220PAOCH1A |
| Product Type | Analog Output Module |
| Series | GE Mark VIe Speedtronic Control System |
| Manufacturer | General Electric (GE) |
| Function | Converts digital control signals into precise analog outputs (current/voltage) to drive actuators and field devices in industrial automation systems. |
| Output Channels | 8 independent analog output channels (current loop) |
| Output Signal Range | 0–20 mA (current loop) with load up to ~900 Ω |
| Resolution | 16-bit (high-precision DAC) |
| Accuracy | ±0.5 % FS over –30 °C to +65 °C |
| Communication Interfaces | Dual RJ-45 Ethernet (IONet) for connection to controller network |
| Power Input | 24 V DC nominal (via 3-pin connector) |
| Operating Temperature | –40 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Isolation | Channel-to-channel galvanic isolation (industrial grade) |
| Dimensions (Board Only) | ~82.6 mm × 41.9 mm × 121 mm |
| Weight (Board Only) | ~1.0 kg |
| Mounting | Rack slot / controller I/O pack mount |
| Protection | Conformal coating for moisture/dust resistance |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the IS220PAOCH1A used for?
It is an analog output module that translates digital control commands into precise analog signals (typically 0–20 mA) to drive field devices such as valves and actuators.
Q2: How many output channels does it support?
It supports 8 independent analog output channels.
Q3: What signal ranges are supported?
Channels typically output 0–20 mA current signals suitable for industrial control loops.
Q4: What voltage does the module require?
It operates on a 24 V DC industrial control supply.
Q5: What are the exact dimensions?
The module’s size is approximately 82.6 mm × 41.9 mm × 121 mm.
Q6: How much does the IS220PAOCH1A weigh?
It weighs about 1.0 kg.
Q7: What temperature range can it operate in?
It can operate in environments from –40 °C to +70 °C.
Q8: Where is this module manufactured?
This GE analog output module is manufactured in the United States.
