Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | GE IS220PAOCH1BE |
| Product Type | Analog Output Terminal Board |
| Series | Mark VIe |
| Output Channels | 8 analog output channels |
| Output Signal Type | 0–20 mA / 4–20 mA (configurable) |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Operating Voltage | 24 V DC (supplied from control system) |
| Operating Temperature | –30 °C to +65 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | DIN-rail mounted |
| Dimensions (H × W × D) | Approx. 170 mm × 120 mm × 45 mm |
| Weight | Approx. 0.6 kg |
| Compliance | Designed for industrial control and turbine applications |
FAQ
FAQ
Q1. What is the main function of the IS220PAOCH1BE?
It provides reliable analog output signals to field devices within GE Mark VIe control systems.
Q2. How many output channels does this module support?
The module supports up to 8 independent analog output channels.
Q3. Which output signal ranges are supported?
It supports standard industrial current outputs such as 0–20 mA and 4–20 mA.
Q4. Is the module electrically isolated?
Yes, it features isolation to reduce noise and protect connected equipment.
Q5. What type of applications typically use this product?
It is commonly used in turbine control, power generation, and heavy industrial automation systems.
Q6. What mounting method is required for installation?
The module is designed for standard DIN-rail mounting.
Q7. Can it operate in harsh industrial environments?
Yes, it is built to operate across a wide temperature range and high humidity conditions.
Q8. Is the IS220PAOCH1BE compatible with Mark VIe systems only?
Yes, it is specifically designed for integration with GE Mark VIe control platforms.
