Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | GE IS230TCISH6C |
| Product Type | Temperature Input Module (TC/RTD) |
| Series | Mark VIe / IS230 series |
| Input Channels | 8 thermocouple or RTD input channels |
| Supported Sensor Types | Thermocouples: Type J, K, T, E, N, R, S, B; RTDs: Pt100, Pt1000 |
| Wiring Configuration | 2-wire, 3-wire, or 4-wire for RTDs |
| Measurement Range | Configurable per sensor type |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Electrical Isolation | Channel-to-channel and channel-to-system isolation |
| Input Scan Time | Typical < 10 ms |
| Rated Supply Voltage | 24 V DC (system supplied) |
| Operating Temperature | –30 °C to +65 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Method | DIN-rail mounting |
| Dimensions (H × W × D) | Approx. 170 mm × 120 mm × 45 mm |
| Weight | Approx. 0.7 kg |
| Typical Application | Temperature monitoring and control in turbines and industrial systems |
FAQ
FAQ
Q1. What is the main function of the IS230TCISH6C?
It measures temperature signals from thermocouples and RTDs for Mark VIe control systems.
Q2. How many input channels does the module support?
It provides 8 independent input channels.
Q3. Which thermocouple types are supported?
Type J, K, T, E, N, R, S, and B thermocouples are supported.
Q4. Which RTD types are supported?
Pt100 and Pt1000 RTDs are supported.
Q5. Does the module support different wiring configurations for RTDs?
Yes, 2-wire, 3-wire, and 4-wire RTD configurations are supported.
Q6. Is electrical isolation provided?
Yes, channel-to-channel and channel-to-system isolation is included.
Q7. Which control systems is this module compatible with?
It is designed for GE Mark VIe / IS230 control platforms.
Q8. What applications typically use this module?
It is commonly used for temperature monitoring in turbines, power generation, and industrial automation systems.
