Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | GE IS230TNTRHIC |
| Product Type | Temperature Input Module (Thermocouple / RTD) |
| Series | Mark VIe / IS230 series |
| Input Channels | 8 thermocouple or RTD input channels |
| Supported Sensor Types | Thermocouples: Type J, K, T, E, N, R, S, B; RTDs: Pt100, Pt1000 |
| Wiring Configuration | 2-wire, 3-wire, or 4-wire for RTDs |
| Measurement Range | Configurable per sensor type |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Electrical Isolation | Channel-to-channel and channel-to-system isolation |
| Input Scan Time | Typical < 10 ms |
| Rated Supply Voltage | 24 V DC (system supplied) |
| Operating Temperature | –30 °C to +65 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Method | DIN-rail mounting |
| Dimensions (H × W × D) | Approx. 170 mm × 120 mm × 45 mm |
| Weight | Approx. 0.7 kg |
| Typical Application | Temperature monitoring and control in turbines and industrial automation systems |
FAQ
FAQ
Q1. What is the main function of the IS230TNTRHIC?
It measures temperature signals from thermocouples and RTDs for Mark VIe control systems.
Q2. How many input channels does it have?
The module provides 8 independent input channels.
Q3. Which thermocouple types are supported?
Type J, K, T, E, N, R, S, and B thermocouples are supported.
Q4. Which RTD types are supported?
Pt100 and Pt1000 RTDs are supported.
Q5. Can it handle different RTD wiring configurations?
Yes, 2-wire, 3-wire, and 4-wire RTD configurations are supported.
Q6. Is electrical isolation included?
Yes, it provides channel-to-channel and channel-to-system isolation.
Q7. Which control systems is this module compatible with?
It is designed for GE Mark VIe / IS230 control platforms.
Q8. What applications commonly use this module?
It is commonly used for temperature monitoring and control in turbines, power generation, and industrial automation systems.
