Technical Specifications (GE Multilin UR Series)
| Parameter | Specification |
|---|---|
| Part Number | UR-5CH (UR 5CH) |
| Manufacturer | GE Multilin (GE Grid Solutions) |
| Series | UR (Universal Relay Series) |
| Product Type | Transducer I/O Module |
| Function | Converts analog signals into digital values for relay monitoring and control |
| Signal Type | Analog current / RTD inputs (module-dependent configuration) |
| Current Input Range | Typically -1 mA to +20 mA DC |
| RTD Capability | Yes (supports RTD temperature inputs in some configurations) |
| Channel Type | Mixed Transducer I/O (analog + RTD variants) |
| Isolation | ~2.5 kV RMS (industrial isolation) |
| Communication | Direct backplane connection to UR relay CPU |
| Configuration | Via relay keypad/LCD or EnerVista UR software |
| Software Tool | GE EnerVista UR Setup |
| Mounting Type | Plug-in module for UR relay chassis |
| Operating Temperature | -40°C to +70°C (industrial grade) |
| Storage Temperature | -40°C to +85°C |
| Dimensions | ~185 × 41 × 173 mm |
| Weight | ~0.9–1.4 kg |
FAQ
FAQ
Q1: What is UR 5CH used for?
It is used to convert field analog signals (like 4–20 mA or RTD temperature signals) into digital data for GE UR protection relays.
Q2: What system does it belong to?
It belongs to the GE Multilin UR (Universal Relay) platform.
Q3: Can it read temperature sensors?
Yes, it supports RTD inputs depending on configuration.
Q4: How is it configured?
Through the relay front panel or GE EnerVista UR software.
Q5: What is the input signal range?
Typically -1 to +20 mA DC for analog channels.
Q6: Is it hot-swappable?
Yes, most UR modules are designed for plug-in replacement in energized racks (with proper procedures).
Q7: What is its role in protection systems?
It provides process measurement inputs (temperature, pressure, flow, etc.) for protection and control logic.
Q8: Where is it commonly used?
In transformer, motor, generator, and feeder protection relays.
