Technical Specifications (GE Multilin UR Series)
| Parameter | Specification |
|---|---|
| Part Number | UR-6DH |
| Manufacturer | GE Multilin (GE Grid Solutions) |
| Series | UR (Universal Relay Series) |
| Product Type | Digital I/O Module |
| Function | Provides digital input and output interface for UR protection relays |
| Digital Inputs | 16 contact inputs |
| Output Types | Form-A / Form-C or mixed configuration (variant dependent) |
| Output Rating | Typically up to ~2–5 A (depending on contact type) |
| Input Voltage Range | 24–48 VDC or AC/DC (variant dependent) |
| Isolation | Up to ~2500 VDC / industrial galvanic isolation |
| Communication | Internal UR backplane (no external protocol) |
| Configuration | GE EnerVista UR Setup software |
| Mounting Type | Plug-in module for UR relay chassis |
| Operating Temperature | -40°C to +70°C |
| Dimensions | ~152 × 178 × 38 mm (6 in × 7 in × 1.5 in) |
| Weight | ~1.1–1.4 kg |
FAQ
FAQ
Q1: What is UR-6DH used for?
It provides digital input and output expansion for GE UR protection relays.
Q2: How many inputs does it have?
It typically supports 16 digital contact inputs.
Q3: What type of outputs does it support?
Depending on configuration, it can include Form-A or Form-C relay outputs.
Q4: What system does it belong to?
The GE Multilin UR (Universal Relay) protection platform.
Q5: What is its main application?
Breaker control, alarm signaling, interlocking, and protection logic execution.
Q6: What is the operating temperature range?
Approximately -40°C to +70°C.
Q7: What is the size of the module?
About 152 × 178 × 38 mm.
Q8: What is the weight?
Roughly 1.1–1.4 kg depending on revision.
