Technical Specifications (GE Multilin UR Series)
| Parameter | Specification |
|---|---|
| Part Number | UR-6TH |
| Manufacturer | GE Multilin (GE Grid Solutions) |
| Series | UR (Universal Relay Series) |
| Product Type | Digital I/O Module |
| Function | Provides digital inputs and relay outputs for protection and control in UR relays |
| Digital Inputs | 8 contact inputs |
| Digital Outputs | 4 Form-A outputs (NO, non-monitored) |
| Output Switching Speed | < 4 ms typical |
| Input Voltage | 24 VDC (typical UR contact input range) |
| Isolation | Industrial galvanic isolation (kV-level, relay-grade) |
| Communication | Internal UR backplane (no external protocol) |
| Configuration | GE EnerVista UR Setup software |
| Mounting Type | Plug-in module for UR chassis |
| Operating Temperature | -20°C to +60°C (typical) |
| Storage Temperature | -40°C to +85°C |
| Dimensions (L × W × H) | ≈ 178 × 152 × 38 mm (7″ × 6″ × 1.5″) |
| Weight | ≈ 1.0 kg (≈ 2.2 lb) |
FAQ
FAQ
Q1: What is UR 6TH used for?
It provides digital input/output expansion for GE UR protection relays.
Q2: How many inputs and outputs does it have?
Typically 8 digital inputs and 4 Form-A outputs.
Q3: What is it used for in protection systems?
Breaker control, alarms, interlocks, and protection logic execution.
Q4: What system does it belong to?
The GE Multilin UR Series protection relay platform.
Q5: Is it programmable?
Yes, via EnerVista UR software and FlexLogic configuration.
Q6: What is the output switching speed?
Less than 4 milliseconds for Form-A outputs.
Q7: What is the operating temperature range?
Typically -20°C to +60°C.
Q8: What is its size and weight?
About 178 × 152 × 38 mm, weight ~1 kg.
