Technical Specifications (GE Multilin UR Series)
| Parameter | Specification |
|---|---|
| Part Number | UR-8NH |
| Manufacturer | GE Multilin (GE Grid Solutions) |
| Series | UR (Universal Relay Series) |
| Product Type | CT/VT Measurement Module |
| Function | Provides current and voltage transformer signal acquisition for protection, metering, and diagnostics |
| CT Inputs | Up to 3-phase CT + ground CT (configuration dependent) |
| VT Inputs | Multi-channel VT inputs (system dependent) |
| Measurement | RMS current, voltage, power system monitoring |
| Special Feature | Enhanced diagnostics + analog data integrity checking |
| Ground Fault Capability | Optional sensitive ground fault detection variant |
| Signal Monitoring | Continuous self-test of CT/VT input circuits |
| Communication | Internal UR backplane (relay CPU interface only) |
| Compatibility | GE Multilin UR-series protection relays |
| Mounting Type | Plug-in module for UR relay chassis |
| Operating Temperature | -40°C to +70°C |
| Dimensions (L × W × H) | ≈ 152 × 178 × 38 mm (6″ × 7″ × 1.5″) |
| Weight | ≈ 0.9–1.15 kg |
FAQ
FAQ
Q1: What is UR 8NH used for?
It is used to measure CT and VT signals for protection and monitoring in UR relays.
Q2: Is UR 8NH a relay?
No, it is a measurement module, not a standalone protection relay.
Q3: What makes UR 8NH different from other UR CT/VT modules?
It features advanced diagnostics and signal integrity checking for higher reliability.
Q4: What systems use it?
GE Multilin UR-series protection relays.
Q5: What is its main role in protection systems?
Providing accurate electrical measurements for protection algorithms (overcurrent, differential, distance, etc.).
Q6: What is the operating temperature?
Typically -40°C to +70°C.
Q7: What are its size and weight?
About 152 × 178 × 38 mm, weight ~0.9–1.15 kg.
Q8: Can it operate alone?
No, it must be installed in a UR relay chassis.
