Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | UR-RHH |
| Manufacturer | GE Multilin (GE Grid Solutions) |
| Series | UR (Universal Relay Series) |
| Product Type | Power Supply Module |
| Function | Provides operating power to UR relay chassis and internal modules |
| Input Voltage Range | 24–48 VDC (low range) or 125–250 V AC/DC (high range, variant dependent) |
| Output Power | ~35 W (typical UR-RH / UR-RHH class) |
| Internal Protection | Fuse-protected (typically 4A / 250 V) |
| Redundancy | Optional redundant power configuration support |
| Self Diagnostics | Built-in health monitoring via UR system self-tests |
| Status Indication | Front panel LED status (power OK / fault / cycling) |
| Communication | Internal UR backplane (no external protocol) |
| Compatibility | GE Multilin UR-series protection relay systems |
| Mounting Type | Plug-in module for UR relay chassis |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Humidity | 5–95% non-condensing |
| Dimensions (H × W × D) | ≈ 165 × 165 × 45 mm |
| Weight | ≈ 1.0 kg (about 2 lb) |
FAQ
FAQ
Q1: What is UR-RHH used for?
It supplies power to GE Multilin UR-series relay systems.
Q2: Is UR-RHH a CPU or I/O module?
No, it is a power supply module, not a processing or I/O module.
Q3: What voltage ranges does it support?
It supports low-range DC (24–48 VDC) or high-range AC/DC (125–250 V) depending on variant.
Q4: Can it be used in all UR relays?
It is compatible only with specific GE UR chassis designs that support RH/HH-type power modules.
Q5: Does it support redundancy?
Yes, many UR systems support dual redundant power supplies.
Q6: What is its main role in the system?
It ensures stable and continuous power to all UR relay modules.
Q7: What are its dimensions?
Approximately 165 × 165 × 45 mm.
Q8: What is its weight?
About 1.0 kg (≈2 lb).
